AccuFab-D1s

Dental 3D Printer

  • . Fast Print Speed
  • . Ultra High Accuracy and Details
  • . Intelligent Print
  • . Long Lifetime and Low Cost

AccuFab-D1s - Your Upgraded Printer

Based on years of experience in dental industry, the upgraded AccuFab-D1s offers users a more intuitive and user-friendly workflow with even faster print speed and better accuracy. With diverse resin material options, it can meet diverse demands in restorative, implant and orthodontic applications. This is the ideal printer solution for all dental customers wishing to enter into the era of digital production.

FAST PRINT SPEED

Featuring a large build volume of 144 x 81 x 160 mm and a fast print speed of up to 50mm/h, the AccuFab-D1s is able to print max 4 arch models in an hour, multiple surgical guides in less than 30mins.

Build volume

144 x 81 x 160mm

Print speed

up to 50mm/h

ULTRA HIGH ACCURACY AND DETAILS

Patented pixel distortion correction algorithm and full HD 1080p projector guarantee ultra-fine print accuracy and details.

Print accuracy

±35μm

INTELLIGENT PRINT

Integrated with advanced print software, the AccuFab-D1s supports intelligent support creation and "one-click" printing, providing user-friendly print experience with higher repeatable consistent accuracy.

icon

LONG LIFETIME AND LOW COST

With long lifetime resin tank, the AccuFab-D1s reduces operation cost. The resin tank can be used for 100,000 layers of printing.

Layers of printing

100,000

Resin tank

EASY POST-CURING

Featuring easy operation and uniform exposure, the Fab Cure maximizes the mechanical & flexural properties of the parts for further operation of dental workflows.

VERSATILE APPLICATION

AccuFab-D1s can be applied in a wide range of applications, such as dental working model, wax-up, surgical guide, gingiva, customized impression tray, bracket transfer tray, etc
slide

slide

slide

slide

slide

slide

slide

slide

TECHNICAL SPECIFICATIONS

Dimension 396 mm * 406 mm * 755 mm
Weight 30 kg
Build Envelope 144 mm * 81 mm * 160 mm
Print Speed 50 mm / h*
Print Accuracy ±35 μm
Layer Thickness 25 μm, 50 μm, 100 μm
DLP Native Resolution 1920 x 1080, 1080 p
Material Option Open
Interface USB / Ethernet / Wi-Fi

FAB CURE

Dimension 200 mm * 200 mm * 325 mm
Weight 6 kg
Turntable Diameter 165 mm
Maximum Part Height 160 mm
Operating Temperature 10 ~ 30 ℃
Power DC24 V, 2.5 A, 60 W
Light Source UV LED
Wavelength 405 nm
LED Power 30 mw / cm²

* The print speed varies and is directly related to the different types of materials or layer thickness.

** Measured by a certain method under certain environment.

*** Notice:SHINING 3D reserves the right to introduce modifications or alterations to any of the specifications and images used in this document.
